The Axle Boat Transporter trailer is built to transport large boats up to 20,000kg. With vertical staunching sockets, the trailer can be adjusted to accommodate a large range boats.
1 models are available in this range
2 Axle Boat Transporter Trailer
The Axle Boat Transporter trailer is built to transport large boats up to 20,000kg. With vertical staunching sockets, the trailer can be adjusted to accommodate a large range boats.
| STANDARD SPECIFICATIONS (APPROX) | |
| Width | 2500mm wide across tyres max width |
| Forward Length | 9050mm |
| Axles | 15″ MTE Ten Stud Axles |
| Suspension | Air Suspension |
| Suspension | Suspension travel 150mm |
| Brakes | 1/4″ x 5-1/2″ Brakes |
| Brakes | Brakes to ADR standards |
| Tyres | 8- 215 x 17.5 x 16 ply tyres |
| Wheels | Alloy Wheels |
| Lighting | LED lights |
| Rub Plate | Fixed Rub Plate |
| Rub Plate Height | 1250mm |
| King Pin | 2″ King Pin |
| Landing Legs | 1- Landing leg pin type |
| Tie Down Points | Certified Lashing Ties |
| Sockets | Vertical Staunching sockets |
| OPTIONAL EXTRAS | |
| Wheels | Aluminium Wheels Machined Finish (12.8kg / Wheel) |
| Wheels | Aluminium Wheels Polished Finish (12.8kg / Wheel) |
| Tyres | Extra spare Tyre and Steel wheel |
| Tyres | Specific branded tyres. (Please State) |
| Suspension | Hydraulic Suspension |
| Power Pack | 5 HP Petrol power Pack |
| Coating | Zinc spray |
